B23 Hybrid receptacles 90° front panel long version square power female 4×4 mm² + 2×2.5mm² + 4xAWG22
B23 Hybrid receptacles 90° front panel long version square power female 4×4 mm² + 2×2.5mm² + 4xAWG22
Download datasheet
58-22020 ENP – 23 – 1 – FSWV1Pbu3PE+2Dst4 – 45S – RS8.36 – 0,5 / G6 / 400 / 250 / 034 B23 Hybrid receptacles front panel mounting 90°, wire termination, long version square, power female, ethernet male, poles 6+4, sez. pwr 4/2,5mmq, 22AWG, cable PUR green, Cat5e + PPE wire, L=0,5m
58-22021 ENP – 23 – 1 – FSWV1Pbu3PE+2Dst4 – 45S – RS8.36 – 1 / G6 / 400 / 250 / 034 B23 Hybrid receptacles front panel mounting 90°, wire termination, long version square, power female, ethernet male, poles 6+4, sez. pwr 4/2,5mmq, 22AWG, cable PUR green, Cat5e + PPE wire, L=1m
58-22022 ENP – 23 – 1 – FSWV1Pbu3PE+2Dst4 – 45S – RS8.36 – 2 / G6 / 400 / 250 / 034 B23 Hybrid receptacles front panel mounting 90°, wire termination, long version square, power female, ethernet male, poles 6+4, sez. pwr 4/2,5mmq, 22AWG, cable PUR green, Cat5e + PPE wire, L=2m
Descrizione
General Data
Product style Receptacle
Size A-side B23
Size B-side RJ45 + Wire power
Gender connector housing A-side Male
Style A-side angled
Gender power contacts A-side Power= Female / Ethernet= Male
No. of poles power contacts A-side 3-pos.+PE+2-pos.
No. of poles data contacts 4-pos.
Hybrid Length cable/wire 0,5-1-2m
Mounting style Square receptacle front panel mounting
Type receptacle housing Long version
Locking type Bajonett
Technical Data
Rated voltage power contacts 600 V AC/ DC
Rated voltage data contacts 50 V AC/ DC
Current Rating power contacts 26 A (4 mm²) + 20 A (2,5 mm²)
Current rating data contacts 1,5 A
Wire cross section power contacts 2,5 mm² + 4,0 mm²
Wire cross section data contacts AWG22
Degree of protection IP67
Performance data core 100 MHz Cat5
