Cord Sets DataTuff® Cat 5e shielded stranded IP67 RJ45
Cord Sets DataTuff® Cat 5e shielded stranded IP67 RJ45
Cat 5e IP67 RJ45 cord set, shielded with stranded conductors (Belden cable 7939A)
Download datasheet
E506001 – Cord Sets, DataTuff® Cat 5e IP67 RJ45 Cord Set, 1m
Download datasheet
E506002 – Cord Sets, DataTuff® Cat 5e IP67 RJ45 Cord Set, 2m
Download datasheet
E506003 – Cord Sets, DataTuff® Cat 5e IP67 RJ45 Cord Set, 3m
Download datasheet
E506005 – Cord Sets, DataTuff® Cat 5e IP67 RJ45 Cord Set, 5m
Download datasheet
E506025 – Cord Sets, DataTuff® Cat 5e IP67 RJ45 Cord Set, 25m
CONDIVIDI / SHARE
Descrizione
Product Overview
| Suitable Applications: | noisy environment, wash down, harsh environment, IIoT, factory or process automation, IP cameras and devices, data communication, etc. |
Physical Characteristics (Overall)
Conductor
| AWG | Stranding | Material |
|---|---|---|
| 24 | 7×32 | TC – Tinned Copper |
| Total Number of Pairs: | 4 |
Insulation
| Material |
|---|
| PO – Polyolefin |
Outer Shield Material
| Material |
|---|
| Bi-Laminate (Alum+Poly) |
Outer Jacket Material
| Material |
|---|
| PVC – Polyvinyl Chloride |
| Overall Nominal Diameter: | 0.295 in. |
| Wiring Scheme: | T568A/B-T568A/B |
| Packaging: | Individually packaged in a clear plastic bag. |
Connectors
Materials
| Description | Material | Color | Type |
|---|---|---|---|
| Plug | Polycarbonate | Black | RJ45 |
| Boot | UL94V-0 flame retardant | ||
| Front Connection | Blades Phosphor Bronze with 50u inch Gold over Nickel Plating |
Electrical Characteristics
| Dielectric Strength: | 1,000 V RMS @ 60 Hz for 1 minute |
| Current Rating: | 1.500 A |
| Insulation Resistance: | 500 M-Ohm Minimum |
| Max Contact Resistance: | 20 mOhm |
Voltage
| UL Voltage Rating |
|---|
| 300 V RMS |
Temperature Range
| Installation Temp Range: | -10°C To +60°C |
| Storage Temp Range: | -40°C To +70°C |
| Operating Temp Range: | -10°C To +60°C |
Mechanical Characteristics
| Max. Pull Tension: | 11.250 lbs |
| Min Bend Radius (Overall Cable): | 2.500 in. |
Termination Interface
| Connection | Durabilities |
|---|---|
| Mated Connection | 750 Cycles |
Standards
| UL Rating: | Riser |
| CSA Rating: | FT4 |
| TIA/EIA Compliance: | Category 5E – TIA 568-C.2, Class D – ISO/IEC 11801:2002 Ed.2 Amendment 2 |
| Other Compliance: | FCC Part 68, Subpart F, IEC 60603-7, Cable Rating NEC: CMR, CMX-Outdoor. CEC: CMR FT4. MSHA. |
Applicable Environmental and Other Programs
| Environmental Space: | Indoor |
| EU Directive 2002/95/EC (RoHS): | Yes |
| EU RoHS Compliance Date (yyyy-mm-dd): | 2006-01-01 |
| MII Order #39 (China RoHS): | EUP 50 |
Flammability, LS0H, Toxicity Testing
| UL voltage rating: | 300 V RMS |
| Safety Listing: | c(UL)us Listed |
Product Notes
| Notes: | US Patent #’s 5, 606, 151; 5, 734, 126. EtherNet/IP is a trademark of ControlNet International, Ltd. under license by Open DeviceNet Vendor Association, Inc., IEC 61076-3-106, IEC 60603-7 |
| Labeling: | Belden Part Number, Performance Acronym, Wiring Scheme and Cord Length. |
