    Distributore ASB-Classic 6 porte M12x2 segnali Plastic 60 mm cavo PUR nero




    Download datasheet
    ASBV 6 5-332/…M – Actuator/sensor distribution box, top-entry, 6-ports, M12 sockets, 5-poles, 2 signals per socket, with integrated control cable. Control cable is suitable for c-track applications. Plastic, 60 mm

    CONDIVIDI / SHARE

    Descrizione

    Technnical data
    Environmental
    Degree of protection IP 67 / NEMA 6P
    Operating temperature range -15°C (+5°F) / +80°C (+176°F)
    Mechanical
    Housing TPU, self-extinguishing
    Insert PA GF, self-extinguishing
    Contact CuZn, pre-nickeled and 0.8 microns gold-plated
    Receptacle shell CuZn, nickel-plated
    O-ring FKM
    Electrical
    Contact resistance ≤5mΩ
    Voltage rating 30 V AC/DC
    Current rating 4 A per port / 12 A max. total
    Insulation resistance > 10-9 Ω
    Accessories (included)
    ZVK 2 dust covers for unused sockets
    ZBS 10 attachable labels
