Distributore ASB-Classic 8 porte LED M8x1 segnale Plastic 26 mm cavo PUR nero

    Richiesta informazioni

    Compila il form e invia una richiesta su questo prodotto





    Distributore ASB-Classic 8 porte LED M8x1 segnale Plastic 26 mm cavo PUR nero




    Download datasheet
    SB 8/LED 3-333/…M – Pluggable miniature actuator/sensor distribution box with LED operation and function indicators, top-entry, 8-ports, M8 socket, 3-poles, 1 signal per socket with integrated control cable. Plastic, 26 mm

    CONDIVIDI / SHARE

    Descrizione

    Technnical data
    Environmental
    Degree of protection IP 67 / NEMA 6P
    Operating temperature range -15°C (+5°F) / +80°C (+176°F)
    Mechanical
    Housing PBT
    Insert TPU, self-extinguishing
    Contact CuSn, pre-nickeled and 0.8 microns gold-plated
    Receptacle shell Brass, nickel-plated
    O-ring FKM
    Electrical
    Contact resistance ≤5mΩ
    Voltage rating 10-30 V DC
    Current rating 2 A per port / 2 A max. total
    Accessories (included)
    ZVKM 2 M8 dust covers for unused sockets
    ZBR 5/10 Attachable labels: 10 pieces
