Descrizione

Technnical data
Environmental
Degree of protection IP 67
Operating temperature range -25°C (-13°F) to +80°C (+176°F)
Weight 300 g
Housing material PUR
Bus system AS-Interface Version 2.1
AS-Interface profile S 7.A.E
I/O configuration 7 hex
ID code F hex
ID2 code (extended ID-code) E hex
Support A/B addressing yes
Electronics power supply AS-Interface
Rated voltage AS-Interface net
Voltage range 26.5–31.6 V DC
Power consumption max. 250 mA
Reverse polarity protection yes
Indication LED green
Input power supply
Voltage range (AS-Interface net) 17–30 V
Total current of all sensors max. 200 mA
Short circuit-proof yes
Inputs Type 2 acc. to IEC 61131-2
Rated input voltage 24 V DC
Signal state “1” Us > 11 V / Is > 6 mA
Signal state “0” Is < 2 mA
Input current at 24 V 15 mA
Input circuit p-switching
Number of digital channels 4
Channel status indicator LED yellow per channel
Output power supply AUX
Rated voltage 24 V DC
Voltage range 10–30 V
Potential separation present
Reverse polarity protection yes/electronic
Indication LED green
