Distributore LioN-Classic Device 8DI (8x M12) M23 Bus connection Plastic 60 mm
Distributore LioN-Classic Device 8DI (8x M12) M23 Bus connection Plastic 60 mm
Download datasheet
0950 ISL 202 – LioN-Classic, Interbus Installation Remote Bus terminal with 8 digital inputs (PNP) and M23 bus connectors. Features: Short circuit detection, protection degree IP67 / NEMA 6P, shock and vibration protected by using potting technology, Plastic, 60 mm
Descrizione
Technnical data
Degree of protection IP 67
Operating temperature range 0°C(+32°F) / +60°C (+140°F)
Weight 500 g
Housing PUR
Slave profile Interbus
ID code 10 dec
Power supply of the electronics (UL)
Nominal voltage 24 V DC
Voltage range 19-30 V DC
Current consumption max. 70 mA
Reverse polarity protection yes
Operating indicator (UL) LED, green
Power supply of the sensors (US)
Nominal voltage 24 V DC
Voltage range 19 V – 30 V DC
Total current of all sensors max. 400 mA
Short circuit protection yes
Sensor short circuit indicator (OVL) LED, red
Sensor pwr. supply indication (US) LED, green
Input levels
Nominal input voltage 24 V DC
Input PNP
Number of digital channels 8
Channel status indicator LED, yellow
