Technnical data
Degree of protection IP 67
Operating temperature range 0°C(+32°F) / +60°C (+140°F)
Weight 580 g
Housing PUR
Slave profile Interbus
ID code 09 dec / ID code 01 dec
Power supply of the electronics (UL)
Nominal voltage 24 V DC
Voltage range 19-30 V DC
Current consumption max. 70 mA
Reverse polarity protection yes
Operating indicator (UL) LED, green
0950 ISL 201:Power supply of the actuators (US)
Nominal voltage 24 V DC
Voltage range 19 V – 30 V DC
Total current of all sensors max. 800 mA
Galvanic isolation yes
Short circuit protection yes
Actuator supply LED, green
0950 ISL 207: Power supply of the actuators (US)
Nominal voltage 24 V DC
Voltage range 19 V – 30 V DC
Potential seperation present
Reverse polarity protection yes/antiparallel diode
Indication LED, green
0950 ISL 201: Output levels
Nominal output current max. 2 A/ch.
max. 15 A/module
Number of channels 8
Channel type PNP, N.O. short circuit proof
Status indicator LED, yellow
0950 ISL 207: Output levels
Nominal output current 2 A per channel
Short circuit proof yes
Max. output current 15 A per module
Overload proof yes
Number of channels 8
Channel type PNP, N.O. short circuit proof
Status indicator LED, yellow per channel
Diagnostic indication LED, red per channel
