Descrizione

Technnical data
Environmental
Degree of protection IP 67
Operating temperature range -10°C (+14°F) to +60°C (+140°F)
Mechanical
Weight 275 g
Housing material PBT
System/sensors power supply US
Rated voltage 24 V DC
Voltage range 19–30 V DC
Power consumption typ. 100 mA
Input power supply US
Voltage range min. (USystem – 1.5 V)
Sensor current 700 mA
Short circuit proof yes
Indication LED green
Input wiring Type 3 acc. to IEC 61131-2
Rated input voltage 24 V DC
Channel type N.O. p-switching
Number of digital channels max. 16
Channel status indicator LED yellow per channel
