Distributore LioN-Link 16DIO interfaccia cavo multipolare Plastic 60 mm
Distributore LioN-Link 16DIO interfaccia cavo multipolare Plastic 60 mm
Download datasheet
0942 UEM 780 – LioN-Link I/O module with 16 digital I/O channels, channels can be used universally as inputs or outputs, multipole cable interface to connect valve terminals, control consoles, manual tool changing devices, IP20 terminal boxes, Plastic, 60 mm
Descrizione
Technnical data
Environmental
Degree of protection IP 67
Operating temperature range -10°C (+14°F) to +60°C (+140°F)
Mechanical
Weight 800 g (with 5 m cable)
Housing material PBT
System/sensors power supply US
Rated voltage 24 V DC
Voltage range 19–30 V DC
Power consumption 140 mA
Input power supply US
Voltage range min. (USystem – 1.5 V)
Sensor current 700 mA
Short circuit proof yes
Indication LED green
Input wiring Type 3 acc. to IEC 61131-2
Rated input voltage 24 V DC
Channel type N.O. p-switching
Number of digital channels max. 16
Output power supply UL
Rated voltage 24 V DC
Voltage range 19–30 V DC
Reverse polarity protection yes/antiparallel diode
Indication LED green
Output wiring
Rated output current 0.5 A per channel
Short circuit proof yes
Max. output current 6 A (3 A per group)
Group 1 Channel 1–8
Group 2 Channel 9–16
Overload proof yes
Number of digital channels max. 16
Channel type N.O. p-switching
