Distributore LioN-M Device 8DO (8x M12) 7/8” Bus connection 7/8” Actuator Supply Plastic 60 mm

    Richiesta informazioni

    Compila il form e invia una richiesta su questo prodotto





    Distributore LioN-M Device 8DO (8x M12) 7/8” Bus connection 7/8” Actuator Supply Plastic 60 mm




    Download datasheet
    0930 DSL 311 – LioN-M, DeviceNet device with 8 digital outputs (2 A) to connect standard actuators, M12 socket, rotary switches for addressing, 7/8” bus connection, 7/8“ actuator supply, Plastic, 60 mm

    CONDIVIDI / SHARE

    Descrizione

    Technical Data
    Environmental

    Degree of protection IP 67
    Operating temperature range -0°C (+32°F) to +60°C (+140°F)
    Mechanical
    Weight 570 g
    Housing material PUR
    Bus system DeviceNet
    Transmission rate max. 500 kBaud
    Autobaud yes
    Address range 0–63 dec
    Rotary address switches 0–63 dec
    Default address 63 dec
    Electronics power supply UL
    Rated voltage 24 V DC
    Voltage range 11–30 V DC
    Power consumption max. 80 mA
    Reverse polarity protection yes
    Indication LED green
    Output power supply US
    Rated voltage 24 V DC
    Voltage range 19–30 V DC
    Potential separation present
    Reverse polarity protection yes/antiparallel diode
    Indication LED green
    Outputs Type 2 A acc. to IEC 61131-2
    Rated output current 2 A per channel
    Short circuit-proof yes
    Max. output current 12 A
    Overload-proof yes
    Number of digital channels 8
    Channel type N.O. p-switching
    Channel status indicator LED yellow per channel
    Diagnostic indication LED red per channel
