Technical Data
Environmental
Degree of protection IP 67
Operating temperature range -0°C (+32°F) to +60°C (+140°F)
Mechanical
Weight 535 g
Housing material PUR
Bus system Profibus
ID number 06EA hex
GSD file Lum_06EA.gsd
Transmission rate max. 12 MBaud
Address range 1–126 dec
Rotary address switches 1–99 dec
Default address 99 dec
Electronics power supply UL
Rated voltage 24 V DC
Voltage range 19–30 V DC
Power consumption typ. 60 mA
Reverse polarity protection yes
Indication LED green
Output power supply US
Rated voltage 24 V DC
Voltage range 19–30 V DC
Potential separation present
Reverse polarity protection yes/antiparallel diode
Indication LED green
Outputs Type 2 A acc. to IEC 61131-2
Rated output current 0.7 A per channel
Short circuit-proof yes
Max. output current 11.2 A per module
Overload-proof yes
Number of digital channels 16
Channel type N.O. p-switching
Channel status indicator LED yellow per channel
Diagnostic indication LED red per channel
Included in delivery/accessories
Dust covers M12 2 pieces
Attachable labels 10 pieces
