Elettrovalvola cablare femmina forma C Led giallo varistore PG7 trasparente
Elettrovalvola cablare femmina forma C Led giallo varistore PG7 trasparente
Download datasheet
GDSL 207 LED 110 VR YE black GM Industrial Standard Field Attachable Connector: Form C, 3-pin (2+1PE; PE across cable outlet), translucent housing, screw type, PG7; with varistor and yellow LED, 110 V AC/DC, 6 A
Download datasheet
GDSL 207 LED 230 VR YE black GM Industrial Standard Field Attachable Connector: Form C, 3-pin (2+1PE; PE across cable outlet), translucent housing, screw type, PG7; with varistor and yellow LED, 230 V AC/DC, 6 A
Download datasheet
GDSL 207 LED 24 VR YE black GM Industrial Standard Field Attachable Connector: Form C, 3-pin (2+1PE; PE across cable outlet), translucent housing, screw type, PG7; with varistor and yellow LED, 24 V AC/DC, 6 A
Download datasheet
GDSNL 207 LED 110 VR YE black GM Industrial Standard Field Attachable Connector: Form C, 3-pin (2+1PE; PE across cable outlet), translucent housing, screw type, PG7; with varistor and yellow LED, 110 V AC/DC, 6 A
Download datasheet
GDSNL 207 LED 230 VR YE black GM Industrial Standard Field Attachable Connector: Form C, 3-pin (2+1PE; PE across cable outlet), translucent housing, screw type, PG7; with varistor and yellow LED, 230 V AC/DC, 6 A
Download datasheet
GDSNL 207 LED 24 VR YE black GM Industrial Standard Field Attachable Connector: Form C, 3-pin (2+1PE; PE across cable outlet), translucent housing, screw type, PG7; with varistor and yellow LED, 24 V AC/DC, 6 A
Descrizione
Technical Data
Number of Pins: 2+PE (PE across cable outlet)
Coding: C
Shielding: Unshielded
Attachment Type: Central Screw
Rated Voltage: 250 V AC/DC, 120 V AC/DC, 30 V AC/DC, 120 V AC/DC, 250 V AC/DC, 30 V AC/DC
Rated Impulse Voltage: 4.0 kV
Operating Voltage: 230 V AC/DC, 110 V AC/DC, 24 V AC/DC, 110 V AC/DC, 230 V AC/DC, 24 V AC/DC
Rated Current*: 6:00 AM
Contact Resistance: ≤ 10 mOhm
Insulation Resistance: ˃ 10^9 Ohm
Mating Cycles: ≤ 50
Type of Connection: Screw
Cable Gland: PG7
Conductor Cross Section: 0.25 – 0.75 mm²
Suitable Cables: Ø 4.5 – 6 mm
Ambient Temperature (Operation)*: -25 °C – +90 °C
Protection Degree / IP Rating**: IP65
