Descrizione

General Data
Product type RJ45 Industrial Ethernet
Size/Number of positions 8-pos.
Size A-side RJ45
Size B-side [e.g. M8, M12, 7/8″ etc.] RJ45
Connector type A-side RJ45 Plug Overmoulded
Connector type B-side RJ45 Stift umspritzt
Termination signal [e.g. clamp, crimp, solder, SMT] IDC
Bus systems Industrial Ethernet
Technical Data
Shielding Shielded
Cable quality [e.g. PP, PVC, TPE etc.] PVC shielded
Wire cross section 4x2xAWG24
Dielectric with standing voltage signal 500 V AC/60sec.
Working voltage signal 125 V DC
IP rating IP 20
Current rating signal 1 A
min. working temperature -20° C
max. working temperature +60° C
Contact resistance standard 10 mOhm
Material Data
Insulator material PC UL 94 V-2
Shell material Copper Alloy
Shell plating Nickel
Housing material TPU angespritzt
Housing color Black
Signal contact material Copper alloy
Plating signal contact (mating area) Gold over nickel
