Industrial Ethernet Cat 5e shielded RJ45 black 4x2xAWG24 TPU UL
Industrial Ethernet Cat 5e shielded RJ45 black 4x2xAWG24 TPU UL
Download datasheet
43-17026 RJ45 field attachable black Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG24, 0,3 m
43-17027 RJ45 field attachable black Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG24, 0,6 m
43-17028 RJ45 field attachable black Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG24, 1,5 m
43-17029 RJ45 field attachable black Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG24, 3 m
Descrizione
General Data
Design Double ended
Style Field attachable connectors
Bus systems Industrial Ethernet
Technical Data
Shielding Shielded
Wire cross section 4x2xAWG24
min. working temperature -40° C
max. working temperature +70° C
Pollution degree 3/2
Working voltage signal 30 V
IP rating IP 20
Current rating signal 1 A
Mating cycles >= 750
Insulation resistance >=100M Ohm
Material Data
Insulator material PBT, UL94
Signal contact material Copper alloy
Plating signal contact (mating area) Gold over nickel
Certificates
Cable UL listed Yes
