Industrial Ethernet Cat 5e shielded RJ45 blue 4x2xAWG26/7 TPU UL

    Richiesta informazioni

    Compila il form e invia una richiesta su questo prodotto





    Industrial Ethernet Cat 5e shielded RJ45 blue 4x2xAWG26/7 TPU UL






    Download datasheet
    17-60000 RJ45 blue Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG26/7, 1 m
    17-60001 RJ45 blue Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG26/7, 2 m
    17-60002 RJ45 blue Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG26/7, 5 m
    17-60003 RJ45 blue Industrial Ethernet Cat.5e Axial shielded 8 pos. TPU UL , 4x2xAWG26/7, 10 m

    COD: d5a6c99c922f Categorie: , , , Tag:
    CONDIVIDI / SHARE

    Descrizione

    General Data
    Product type RJ45 Industrial Ethernet
    Size/Number of positions 8-pos.
    Size A-side RJ45
    Size B-side [e.g. M8, M12, 7/8″ etc.] RJ45
    Connector type A-side RJ45 Plug Overmoulded
    Connector type B-side RJ45 Stift umspritzt
    Termination signal [e.g. clamp, crimp, solder, SMT] IDC
    Bus systems Industrial Ethernet
    Technical Data
    Shielding Shielded
    Cable quality [e.g. PP, PVC, TPE etc.] TPU UL, halogenfree
    Wire cross section 4x2xAWG26/7
    Dielectric with standing voltage signal 500 V AC/60sec.
    Working voltage signal 125 V
    IP rating IP 20
    Current rating signal 1 A
    min. working temperature -25° C
    max. working temperature +60° C
    Contact resistance standard 10 mOhm
    Material Data
    Insulator material PBT GF UL 94 V-0
    Shell material Copper Alloy
    Shell plating Nickel
    Housing material TPU angespritzt
    Housing color Blue
    Signal contact material Copper alloy
    Plating signal contact (mating area) Gold over nickel
