M12 femmina diritto A-coded PUR nero
M12 femmina diritto A-coded PUR nero
PUR NERO
Download datasheet
RKT 4-3-224 M12 A-coded female axial 4 pos. PUR nero 3×0,34mm², unshielded.
Download datasheet
RKT 4-225 M12 A-coded female axial 4 pos. PUR nero 4×0,34mm², unshielded.
Download datasheet
RKT 4-500 M12 A-coded female axial 4 pos. PUR nero 4×0,34mm², unshielded.
Download datasheet
RKT 5-72 M12 A-coded female axial 5 pos. PUR nero 5×0,34mm², unshielded.
Download datasheet
RKT 5-87 M12 A-coded female axial 5 pos. PUR nero 5×0,34mm², unshielded.
Download datasheet
RKT 5-228 M12 A-coded female axial 5 pos. PUR nero 5×0,50mm², unshielded.
Download datasheet
RKT 5-293 M12 A-coded female axial 5 pos. PUR nero 5×0,34mm², unshielded.
Download datasheet
RKT 5-411 M12 A-coded female axial 5 pos. PUR nero 5×0,50mm², unshielded.
Download datasheet
RKT 8-6-337 M12 A-coded female axial 8 pos. PUR nero 6×0,34mm², unshielded.
Download datasheet
RKT 8-282 M12 A-coded female axial 8 pos. PUR nero 7×0,25mm², unshielded.
Download datasheet
RKT 8-344 M12 A-coded female axial 8 pos. PUR nero 8×0,25mm², unshielded.
Download datasheet
RKT 12-346 M12 A-coded female axial 12 pos. PUR nero 12×0,25mm², unshielded.
Download datasheet
RKT 12-10-345 M12 A-coded female axial 12 pos. PUR nero 10×0,25mm², unshielded.
M12 Standard Sensor/Actuator Single-Ended Cordset: Female, straight, A-coded, translucent body:
224: 4-pin, 230 V AC/DC, 4 A; PUR black cable, 3-wires, 0.34 mm²
225: 4-pin, 230 V AC/DC, 4 A; PUR black cable, 4-wires, 0.34 mm²
500: 4-pin, 230 V AC/DC, 4 A; PUR black cable, 4-wires, 0.34 mm²
72: 5-pin, 50 V AC / 60 V DC, 4 A; PUR black cable, 5-wires, 0.34 mm²
87: 5-pin, 50 V AC / 60 V DC, 4 A; PUR black cable, 5-wires, 0.34 mm²
228: 5-pin, 50 V AC / 60 V DC, 4 A; PUR black cable, 5-wires, 0.50 mm²
293: 5-pin, 50 V AC / 60 V DC, 4 A; PUR black cable, 5-wires, 0.34 mm²
411: 5-pin, 50 V AC / 60 V DC, 4 A; PUR black cable, 5-wires, 0.50 mm²
337: 8-pin, 30 V AC/DC, 2 A; PUR black cable, 6-wires, 0.34 mm²
282: 8-pin, 30 V AC/DC, 2 A; PUR black cable, 7-wires, 0.25 mm²
344: 8-pin, 30 V AC/DC, 2 A; PUR black cable, 8-wires, 0.25 mm²
345: 12-pin, 30 V AC/DC, 1.5 A; PUR black cable, 10-wires, 0.25 mm²
346: 12-pin, 30 V AC/DC, 1.5 A; PUR black cable, 12-wires, 0.25 mm²
Descrizione
Codifica A
Rated Voltag [V]
250V 3P e 4P
60V 5P
30V 6P, 8P, 12P
Current Rating [A]
3P-4P-5P 4A
6P-8P 2A
12P 1,5A
