M8 screw front panel mounting sch. female B-coded THR h=9mm
M8 screw front panel mounting sch. female B-coded THR h=9mm
M8x1 Sockets THR
Download datasheet
42-01329 SAL-8BS-FK5-X9/THR M8 B-coded female axial front panel mounting 5 pos. THR, with shielding, h=9mm, 30 V AC / 30 V DC, 3A
Descrizione
Technical Data
Shielding Shielded
General Data
Size/Number of positions 5-pos.
Contact type Female connector axial
Coding B-coded
Mounting options [e.g. front/back panel mounting etc.] Front panel mounting
Locking type Screwable
Termination signal [e.g. clamp, crimp, solder, SMT] THR
Installation height 9 mm
Style Sockets
Technical Data
Shielding Shielded
Material Data
Insulator material LCP GF
Insulator color Black
Housing material copper alloy
Housing color Nickel
Signal contact material Copper alloy
Plating signal contact (mating area) Gold over nickel
Specifications
Standard current rating IEC 61076-2-104
