Patch Cords RJ45 UTP CMP
CAT5E UTP CMP Patch CordsDescrizione
Product Overview
| Suitable Applications: | IBDN System 1200, TIA Category 5E, ISO Class D, 1000BASE-T, 100BASE-T |
Physical Characteristics (Overall)
| Total Number of Pairs: | 4 |
| Nominal diameter of the cable: | 0.22 in |
| Wiring Scheme: | T568A/B-T568A/B |
| Packaging: | Individually packaged in a clear plastic bag. |
Connectors
Materials
| Description | Material | Color |
|---|---|---|
| Boot | Elastomer | Translucent |
| Conductor | BC – Bare Copper | |
| Front Connection | Blades Phosphor Bronze with 50u inch Gold over Nickel Plating | |
| Inner Jacket | PVC – Polyvinyl Chloride | |
| Insulation | PO – Polyolefin | |
| Outer Jacket | PVC – Polyvinyl Chloride |
Electrical Characteristics
| Dielectric Strength: | 1,000 V RMS @ 60 Hz for 1 minute |
| Current Rating: | 1.500 A |
| Insulation Resistance: | 500 M-Ohm Minimum |
| Max Contact Resistance: | 20 mOhm |
Temperature Range
| Installation Temp Range: | -10°C To +60°C |
| Storage Temp Range: | -40°C To +70°C |
| Operating Temp Range: | -10°C To +60°C |
Mechanical Characteristics
| Min Bend Radius (Overall Cable): | 1.040 in |
| Plug /Jack Compatibility: | RJ45 |
Termination Interface
| Connection | Durabilities |
|---|---|
| Mated Connection | 750 Cycles |
Standards
| UL Rating: | Riser |
| ANSI/TIA Category: | Category 5e |
| Telecommunications Standards: | Category 5E – TIA 568-C.2, Class D – ISO/IEC 11801:2002 Ed.2 Amendment 2 |
| Other Standards: | FCC Part 68, Subpart F, IEC 60603-7 |
Applicable Environmental and Other Programs
| Environmental Space: | Plenum |
| EU Directive 2002/95/EC (RoHS): | Yes |
| EU RoHS Compliance Date (yyyy-mm-dd): | 2006-01-01 |
| MII Order #39 (China RoHS): | EUP 50 |
Flammability, LS0H, Toxicity Testing
| Safety Listing: | c(UL)us Listed |
Part Number
| Related Parts: | CAT5E Modular Jacks and Couplers, CAT5E Patch Panels |
Variants
| Item # | Color | Length |
|---|---|---|
| C502100030 | Black | 30 ft |
| C502100033 | Black | 33 ft |
| C502100036 | Black | 36 ft |
| C502100040 | Black | 40 ft |
| C502100043 | Black | 43 ft |
| C502100046 | Black | 46 ft |
| C502100049 | Black | 49 ft |
| C502100052 | Black | 52 ft |
| C502100056 | Black | 56 ft |
| C502100059 | Black | 59 ft |
| C502100062 | Black | 62 ft |
| C502100066 | Black | 66 ft |
| C502100069 | Black | 69 ft |
| C502100072 | Black | 72 ft |
| C502100079 | Black | 79 ft |
| C502100082 | Black | 82 ft |
| C502100085 | Black | 85 ft |
| C502100092 | Black | 92 ft |
| C502100102 | Black | 102 ft |
| C502106002 | Blue | 2 ft |
| C502106004 | Blue | 4 ft |
| C502106005 | Blue | 5 ft |
| C502106006 | Blue | 6 ft |
| C502106007 | Blue | 7 ft |
| C502106010 | Blue | 10 ft |
| C502106012 | Blue | 12 ft |
| C502106015 | Blue | 15 ft |
| C502106020 | Blue | 20 ft |
| C502106025 | Blue | 25 ft |
| C502106030 | Blue | 30 ft |
| C502106050 | Blue | 50 ft |
| C502106075 | Blue | 75 ft |
| C502106080 | Blue | 80 ft |
| C502106090 | Blue | 90 ft |
| C502108004 | Gray | 4 ft |
| C502108005 | Gray | 5 ft |
| C502108007 | Gray | 7 ft |
| C502108010 | Gray | 10 ft |
| C502108025 | Gray | 25 ft |
| C502108035 | Gray | 35 ft |
| C502108050 | Gray | 50 ft |
| C502108066 | Gray | 66 ft |
| C502105050 | Green | 50 ft |
| C502105070 | Green | 70 ft |
| C502105075 | Green | 75 ft |
| C502105080 | Green | 80 ft |
| C502105100 | Green | 100 ft |
| C502105150 | Green | 150 ft |
| C502103010 | Orange | 10 ft |
| C502103015 | Orange | 15 ft |
| C502103020 | Orange | 20 ft |
| C502107025 | Purple | 25 ft |
| C502116025 | TIA Blue | 25 ft |
| C502116050 | TIA Blue | 50 ft |
| C502109003 | White | 3 ft |
| C502109004 | White | 4 ft |
| C502109007 | White | 7 ft |
| C502109010 | White | 10 ft |
| C502109012 | White | 12 ft |
| C502109015 | White | 15 ft |
| C502109020 | White | 20 ft |
| C502109025 | White | 25 ft |
| C502109050 | White | 50 ft |
| C502104035 | Yellow | 35 ft |
