Distributore ASB-N 8 porte LED M12x2 segnali Stainless Steel 60 mm cavo PVC nero

    Richiesta informazioni

    Compila il form e invia una richiesta su questo prodotto





    Distributore ASB-N 8 porte LED M12x2 segnali Stainless Steel 60 mm cavo PVC nero




    Download datasheet
    ASNBV 8/LED 5-278/…M – Actuator/sensor distribution box with LED operation and function indicators, housing and receptacle shells in staniless steel, top-entry, 8-ports, M12 sockets, 5-poles, 2 signals per socket, with integrated control cable. Especially designed for use in food processing equipment applications. Stainless Steel, 60 mm

    CONDIVIDI / SHARE

    Descrizione

    Technnical data
    Environmental
    Degree of protection IP 67 / IP 69 K
    Operating temperature range -25°C (-13°F) / +70°C (+158°F)
    Mechanical
    Housing Stainless steel
    Housing back cover PVC
    Insert PVC
    Contact CuSn, gold over nickel plated
    Receptacle shell Stainless steel
    O-ring EPDM
    Electrical
    Contact resistance ≤ 5 mΩ
    Voltage rating 10-30 V DC
    Current rating 4A per port, 12A max. total
    Insulation resistance > 10-9 Ω
    Accessories (included)
    PZVK 4 PVC dust covers for unused sockets
