Distributore ASB-Classic 8 porte LED M12x1 segnale Plastic 54 mm cordine unipolari sul retro
Distributore ASB-Classic 8 porte LED M12x1 segnale Plastic 54 mm cordine unipolari sul retro
Download datasheet
ASB 8/LED 5-4/1.5M – Actuator/sensor distribution box with LED operation and function indicators and single wire connection in rear, top-entry, 8-ports, M12 sockets, 4-poles, 1 signal per socket. Excellent solution for panel-mount applications. Plastic, 54 mm
Descrizione
Technnical data
Environmental
Degree of protection IP 67 / NEMA 6P
Operating temperature range -15°C (+5°F) / +80°C (+176°F)
Mechanical
Housing TPU, self-extinguishing
Insert PA GF, self-extinguishing
Contact CuZn, pre-nickeled and 0.8 microns gold-plated
Receptacle shell CuZn, nickel-plated
O-ring FKM
Electrical
Contact resistance ≤5mΩ
Voltage rating 10-30 V DC
Current rating 4 A per port / 12 A max. total
Insulation resistance > 10-9 Ω
Accessories (included)
ZVK 2 dust covers for unused sockets
ZBS 10 attachable labels
