Elettrovalvola cablare femmina forma A varistore PG11 nero
Elettrovalvola cablare femmina forma A varistore PG11 nero
Download datasheet
GDM210B-V3U-10D GDM Standard DIN Standard Field Attachable Connector: Form A, 3-pin (2+1PE; PE across cable outlet), black housing, screw type, PG11; with bridge rectifier and varistor, 230 V AC/DC, 1 A
Descrizione
GDM Series Valve Connectors, Type A, Field Attachable Female Connectors, Protection Circuit: with bridge rectifier and varistor
Valve connector GDM series, type A, female connector, field attachable
(Construction Type) Standard DIN EN 175301-803-A
Approvals VDE, SEV
Technical Data
No. of Pins 2 + PE
Ambient Temperature -25 °C to +90 °C
Electrical Data
Operating Voltage: 230 V AC/DC
Rated Current*: 1 A
Type of Connection: Screw
Cable Gland: PG11
Conductor Cross Section: 0.25 – 1.5 mm²
Suitable Cables: Ø 4.5 – 11 mm
Ambient Temperature (Operation)*: -40 °C – +125 °C
Protection Degree / IP Rating**: IP65
