Industrial Ethernet Cat 5e shielded RJ45 black 4xAWG24 TPU UL
Industrial Ethernet Cat 5e shielded RJ45 black 4xAWG24 TPU UL
Download datasheet
17-140013 RJ45 black Industrial Ethernet Cat.5e Axial shielded 4 pos. TPU UL , 4xAWG24, 1 m
17-140023 RJ45 black Industrial Ethernet Cat.5e Axial shielded 4 pos. TPU UL , 4xAWG24, 2 m
17-140033 RJ45 black Industrial Ethernet Cat.5e Axial shielded 4 pos. TPU UL , 4xAWG24, 5 m
17-140043 RJ45 black Industrial Ethernet Cat.5e Axial shielded 4 pos. TPU UL , 4xAWG24, 10 m
Descrizione
General Data
Product type RJ45 Industrial Ethernet
Size/Number of positions 4- pos.
Connector type A-side RJ45 Plug Overmoulded
Connector type B-side RJ45 Stift umspritzt
Termination signal [e.g. clamp, crimp, solder, SMT] IDC
Bus systems Industrial Ethernet
Technical Data
Shielding Shielded
Cable quality [e.g. PP, PVC, TPE etc.] TPU UL, halogenfree
Wire cross section 4xAWG24
Dielectric with standing voltage signal 500 V AC/60sec.
Working voltage signal 125 V DC
IP rating IP 20
Current rating signal 1,2 A
min. working temperature -20° C
max. working temperature +60° C
Contact resistance standard 10 mOhm
Material Data
Insulator material PBT GF UL 94 V-0
Shell material Copper Alloy
Shell plating Nickel
Housing material TPU angespritzt
Housing color Black
Signal contact material Copper alloy
Plating signal contact (mating area) Gold over nickel
