    M12-D-sub maschio-maschio diritto B-coded Profibus PUR


    Download datasheet
    0975 254 105 – PROFIBUS Data Double-Ended Cordset: Male straight B-coded black M12 Standard to male angled SUB-D-coded SUB-D, shielded, + 4.75 … +5.25 V DC, 12.5 mA; PUR violet cable, 2-wires, 0.34 mm²





    CONDIVIDI / SHARE

    Descrizione

    Rated Voltage: 60 V
    Rated Impulse Voltage: 1.5 kV
    Operating Voltage: 50 V AC / 60 V DC
    Rated Current*: 4 A
    Data Transmission: PROFIBUS
    Technical Data Side 1
    Shielding: Shielded
    Operating Voltage: + 4.75 … +5.25 V DC
    Rated Current*: 12.5 mA
    Data Transmission: PROFIBUS
    Technical Data Side 1
    Product Sub Family: M12 Standard
    Type of Contact / Gender: Male
    Connector Design: Straight
    Attachment Type: Coupling Screw
    Number of Pins: 5
    Coding: B
    Contact Resistance: ≤ 10 mOhm
    Insulation Resistance: ˃ 10^9 Ohm
    Mating Cycles: ≤ 100
    Ambient Temperature (Operation)*: – 25 °C – + 80 °C
    Protection Degree / IP Rating**: IP65, IP67
    Technical Data Side 2
    Product Sub Family, Side 2: SUB-D
    Type of Contact / Gender, Side 2: Male
    Connector Design, Side 2: Angled
    Number of Pins, Side 2: 9
    Coding, Side 2: SUB-D
    Contact Resistance, Side 2: ≤ 20 mOhm
    Ambient Temperature (Operation), Side 2*: 0 °C – + 60 °C
    Protection Degree / IP Rating, Side 2**: IP40
