M12 maschio 90°-femmina diritto CanOpen-DeviceNet
M12 maschio 90°-femmina diritto CanOpen-DeviceNet
PUR NERO
Download datasheet
0935 253 112 – CANopen / DeviceNet Data Double-Ended Cordset: Male angled A-coded black M12 Standard to female straight A-coded black M12 Standard, 50 V AC / 60 V DC, 4 A; PUR black cable, 4-wires, Data: 2×0.25 mm² + Power: 2×0.34 mm²
CONDIVIDI / SHARE
Descrizione
Codifica A
Shielding: Unshielded
Ambient Temperature (Operation)*: – 40 °C – + 80 °C
Protection Degree / IP Rating**: IP65, IP67, IP68 (1 m / 24 h), IP69K
Rated Voltage: 60 V
Rated Impulse Voltage: 1.5 kV
Operating Voltage: 50 V AC / 60 V DC
Rated Current*: 4 A
Data Transmission: CANopen / DeviceNet
