M12 maschio diritto CanOpen-DeviceNet
M12 maschio diritto CanOpen-DeviceNet
PUR NERO
Download datasheet
P.n.: 0935 253 104 – CANopen / DeviceNet Data Single-Ended Cordset: M12 Standard, male, straight, 5-pin, A-coded, black body, 50 V AC / 60 V DC, 4 A; PUR black cable, 4-wires, Data: 2×0.25 mm² + Power: 2×0.34 mm²
CONDIVIDI / SHARE
Descrizione
Codifica A
Product Sub Family: M12 Standard
Number of Pins: 5
Data: blue, white + Power: red, black
Conductors: 2×0.25 mm² (24 AWG)+ Power: 2×0.34 mm² (22 AWG) PUR Halogen Free black Ø 6.7 mm
Rated Voltage: 60 V
Rated Impulse Voltage: 1.5 kV
Operating Voltage: 50 V AC / 60 V DC
Rated Current*: 4 A
Data Transmission: CANopen / DeviceNet
Ambient Temperature (Operation)*: – 40 °C – + 80 °C
Protection Degree / IP Rating**: IP65, IP67, IP68 (1 m / 24 h), IP69K
Disposizione dei PIN
