Distributore LioN-Classic Device derivazione integrata 8DI (8x M12) M23 Power Supply Plastic 60 mm
Distributore LioN-Classic Device derivazione integrata 8DI (8x M12) M23 Power Supply Plastic 60 mm
Download datasheet
0950 ISL 205 – LioN-Classic, Interbus Remote Bus terminal with 8 digital inputs (PNP), Installation Remote Bus drop and M23 bus connectors. Features: Short circuit detection, protection degree IP67 / NEMA 6P, shock and vibration protected by using potting technology, Plastic, 60 mm
Descrizione
Technnical data
Degree of protection IP 67
Operating temperature range 0°C(+32°F) / +60°C (+140°F)
Weight 580 g
Housing PUR
Slave profile Interbus
ID code 11 dec
Power supply of the electronics (UL)
Nominal voltage 24 V DC
Voltage range 19-30 V DC
Current consumption max. 120 mA
Reverse polarity protection yes
Operating indicator (UL) LED, green
Power supply of the sensors (US)
Nominal voltage 24 V DC
Voltage range 19 V – 30 V DC
Total current of all sensors max. 400 mA
Short circuit protection yes
Sensor short circuit indicator (OVL) LED, red
Input levels
Nominal input voltage 24 V DC
Input PNP
Number of digital channels 8
Channel status indicator LED, yellow
